General purpose 3/8


code : 1901-KHNC010-150

REFERANCE: 1901-KHNC010-150-220AC
MAIN SERIES: General Purpose
FUNCTION: 2/2 Ways
POSITION: Normally Closed
OPERATION TYPE: Assisted Lift (Zero Differential Pressure)
SEAT SEAL MATERIAL: NBR Diaphragm / NBR Seal
PORT SIZE: 3/8”
ORIFICE: 15mm
Kv: 65.00 l/min
Pmin-Pmax (bar): 0-10 bar
Tmin / Tmax (°C): -10 °C / 80 °C
WEIGHT: 0.605 Kg
COIL VOLTAGE - TOLERANCE: 12,24,220,230V AC/DC
